Name: Downhole Use Oil-resistant V Type Oilfield Rubber Swab Cup With Long Service Life For Harsh Oil Extraction
Brand: Shanghai Qinuo Industry Co., Ltd.
SKU: TA/RTL
Price: 3.00 USD
Availability: InStock

Nhà Sản phẩm Cốc dầu Swab

Downhole Use Oil-resistant V Type Oilfield Rubber Swab Cup With Long Service Life For Harsh Oil Extraction

Thông tin chi tiết sản phẩm:

Nguồn gốc:	Thượng Hải, Trung Quốc
Hàng hiệu:	Royal Way
Chứng nhận:	ISO 9001
Số mô hình:	TA/RTL

Thanh toán:

Số lượng đặt hàng tối thiểu:	500pcs
Giá bán:	1~5usd/pcs
chi tiết đóng gói:	Bao bì carton 404040cm
Thời gian giao hàng:	20 ngày
Điều khoản thanh toán:	T/T, Liên minh phương Tây, L/C, PayPal
Khả năng cung cấp:	10000 chiếc mỗi tuần

Tiếp xúc

Chi tiết sản phẩm

Kích cỡ::	2 3/8" 2 7/8" 3 1/2" hoặc các zise tùy chỉnh	Vật liệu::	ống lót cao su + nhôm hoặc thép
Môi trường::	Hoạt động quét ở các mỏ dầu	Màu sắc:	Màu đen hoặc màu tùy chỉnh
các loại::	6000-10000psi	Trường ứng dụng:	Quét tải nhẹ trung bình
Hiệu quả chi phí:	Giải pháp hợp lý và tiết kiệm chi phí	Phong tục:	Bao bì carton + Pallet
Bảo hành:	5 năm	Xếp hạng áp lực:	lên đến 10.000 psi
Sức chống cự:	Chống mài mòn và hóa chất	Bưu kiện:	Thùng carton + túi nhựa

V Series Swab Cup for Sand-Laden Fluids:

The V Series Swab Cup from Shanghai Qinuo is engineered for outstanding performance in oil and gas well operations involving abrasive and sand-laden fluids. Available in light-duty and heavy-duty designs, this all-rubber cup provides an efficient and reliable seal in tubing and casing during swabbing operations. The unique upturned lip profile ensures smooth passage through tight or irregular sections of the wellbore while allowing the cup to invert easily to release heavy fluid loads, ensuring smooth operation without equipment stress.
Constructed from Qinuo’s special Frac Fluid compound, the cup offers exceptional resistance to wear, high tensile strength, and strong chemical stability, even in aggressive downhole environments. The superior abrasion resistance extends the service life of the cup, reducing replacement frequency and operational costs. Designed for flexibility across various well conditions, the number of swab cups used per tool can be customized to match the depth and pressure requirements. Qinuo’s V Series Swab Cups are trusted by oilfield professionals for their durability, precision molding, and consistent high performance.

Downhole Use Oil-resistant V Type Oilfield Rubber Swab Cup With Long Service Life For Harsh <img src=

Normal size(In)	OD(In/mm)	ID(In/mm)	Core and Description	Weight(g)
4 1/2	4.062/103.17	2.420/61.47	Steel Core Swab Cup	137
5 1/2	4.970/126.24	2.920/74.17	Steel Core Swab Cup	320
7	6.475/164.47	3.545/90.04	Steel Core Swab Cup	560

Our Swab Cups are produced from a newly developed rubber in the popular Guiberson* profile in either a nitrile or Frac Fluid compound. These cups can also be produced in other specified materials. Our cups are designed for durability and perform under the toughest conditions.

ISO9001: 2015 & SGS certificate:

Shanghai Qinuo Industry Co., Ltd, founded in 2013, has more than a decade of experience in producing and supplying rubber fittings for the oil and gas industry. With annual sales exceeding $10 million and a strict ISO9001 quality system, our wholly owned Nantong Ruowei Seal factory is equipped with 30+ vulcanizing machines and advanced facilities. We manufacture over 20 types of seals, O-rings, and customized rubber components for demanding applications. With a monthly capacity of over 40 tons, our products are trusted by customers in more than 100 countries worldwide.

Downhole Use Oil-resistant V Type Oilfield Rubber Swab Cup With Long Service Life For Harsh <img src= Available types of Swab cups:

TA style:

TA is a medium load Swab Cup built around a steel or aluminum bushing for use in most sizes of tubing or drill pipe. When under load, it will compress to form a solid rubber mass for maximum lifting capacity and minimum wear. Manufactured from a newly developed rubber compound, these cups provide our customers with a high quality North American product. Our special Frac Fluid compound is developed for the ultimate in durability and performance. These Frac Swab Cups are designed to perform under the toughest conditions.

Downhole Use Oil-resistant V Type Oilfield Rubber Swab Cup With Long Service Life For Harsh <img style= V style:

Shanghai Qinuo carries the V Series Swab Cup in a light duty and heavy duty all rubber cup that is suited for use in fluids with high concentrations of suspended sand. The upturned lips pass easily through tight spots and will invert to dump excessive loads. The number of cups used will vary with conditions.Our special Frac Fluid compound has excellent abrasion resistance high tensile strength and outstanding resistance to chemical attack.

TUF style:

The design of the GE-TUF cup, with its internal metal reinforcement which maintains the shape of the cup, makes this an excellent choice for deep hot wells or rough and corroded tubing and casing. Strong enough for heavy loads, its flexability also allows it to work in light load situations.

NUF style:

The GE-NUF is a heavy load all rubber cup that provides maximum lifting capacity. Bonded to either standard steel or aluminum bushings, and available in a wide range of sizes, this cup is a good choice for deep well applications. This cup is designed for high performance and heavy loads. Made of our special Frac Fluid compound, it will perform under the toughest conditions.

Part Name	MV Style, TA style, TUF style, NUF style and V style
Environment	oil, gas, gas condensate
Available Material	FKM, , HNBR and nitrile rubber with or without Brass or Steel

Packing and shipment:

Express: S.F. ,DHL,UPS, TNT, FedEx ect, for urgent and small order.
Air shipment: air port to air port or air port to door.
Sea shipment: suitable for bulk goods. it will takes more longer time than air shipment.

Downhole Use Oil-resistant V Type Oilfield Rubber Swab Cup With Long Service Life For Harsh <img src= Company View:

Downhole Use Oil-resistant V Type Oilfield Rubber Swab Cup With Long Service Life For Harsh <img src= Other relative rubber products:

Downhole Use Oil-resistant V Type Oilfield Rubber Swab Cup With Long Service Life For Harsh </p>
<p class= FAQ:

Q.Why Choose Qinuo industry?
We provide them with one-stop service from R & D to production to satisfy their customization needs.
We are based in the most big city Shanghai, which have two internation airports and two deepwater ports, we can ship the goods out at anytime while some inland suppliers need take a more time.
Q.What is your advantage?
1. Has sound and mature supporting supply chain
2. Lower mold costs
3. High efficiency of development and design ability and short process time.
4. Cost effective and good service attitude.
5. More professional export sales staff who are all know rubber processing very well.
Q.Are you manufacture or trading company?
We are manufacture. Our factory located in Haimen District, Nantong City, Jiangsu Province.
Q.How can we guarantee quality?
Always a pre-production sample before mass production;Always final Inspection before shipment;
Q.Can I get some samples?
Sure, samples are available,3-10 samples are for free. Please note that only needs to pay for shipping cost.
Q.Can you produce OEM products?
Yes, we can produce by your samples or 3D drawings. We can build the molds and fixtures.
Q.What's the term of payment?
Amount < US$5000,100% paid in advance by paypal or T/T;
Amount >= US$5000, 30% paid in advance, 70% balance before shipment by T/T
Q.Can you manage the shipment?
Sure, we can arrange different ship ways according to the goods final packing: by express, by air or by sea.
